BERGEN TANK
| Call sign | LATV | ||
| IMO nr | 9436161 | ||
| Year | 2010 | ||
| DWT | 850 | ||
| LOA | 47,85m | ||
| Beam | 10,00m | ||
| Draft | 2,85m | ||
| GRT | 498 |
IMO 9436161
CALL SIGN: LATV
| GENERAL | |
| Where Built : | Nevsky Shipbuilding, St Petersburg, Russia/Nauta Shipyard Poland |
| Date Delivered: | 8 October 2010 |
| Type of vessel: | Tanker for oil, flashpoint > 60 ° C. |
| Type of hull: | Double Hull |
| NATIONALITY, REGISTER, AND CLASS INFORMATION | |
| Nationality/flag | NOR |
| Class | Bureau Veritas |
| Register notation | BV 1 *HULL, *MACH.,Oil Tanker ESP -flashpoint > 60 ° C, AUT-UMS, Coastal Area |
| MAIN PARTICULARS | |
| LOA (Length Over All): | 47,85 Metres |
| Extreme breadth: | 10,00 Metres |
| KTM (Keel to Masthead): | 15,3 Metres |
| Draught (fully loaded summer) | 2,85 Metres |
| Air draft in normal SBT condition? | 12,95 Metres |
| BCM (Bow to Center Manifold): | 21,4 Metres |
| Net Tonnage: | 174 |
| Gross Tonnage: | 498 |
| DWT | 850 |
| TANK ARRANGEMENT AND CAPACITY | |
|
Number of cargo tanks |
6 |
|
Groups / Tank Capacities (m3 98%)
|
CT1 97,3 CT 2 213,248 CT 3P 114,856 CT4 SB 114,856 CT5 147,588 CT6/slop 44,394 |
| Total cubic capacity 98%: | 732,242 Cu. Metres |
| Number of segregations | 6 |
| Number of slop tanks | 1 |
| Slop tank(s) capacity 98%: | 44,394 Cu. Metres |
| Cargo pumps |
2 x 400 Cu. Metres/Hour (Allweiler screw pump) 1 x 50 Cu.Metres/Hour slop pump (Allweiler screw pump) |
| Pumping capacity | 800 Cu.Metres/Hour total |
| Vapour return | No |
| IGS | No |
| Tank coating | Modified Epoxy, JOTUN Tankguard |
| Heating arrangement | Heatexchanger Diathermic oil |
| Heating capacity | 70° C. |
| Tank gauging system | Pressure sensors |
| Closed loading/sampling | Yes |
| Hose crane | SWL 0,99t |
| MOORING EQUIPTMENT | |
| Number of ropes on drums forward | 4 |
| Number of ropes on drums afterward | 4 |
| Number of ropes on drums midship | 0 |
| MACHINERY AND PROPULSION | |
| Main engine | 2 x Mitsubishi S12A2 rated output 375 kW AT 1500 RPM |
| Service speed | 9 |
| Aux. engines | 1 x Kohler harbour generator 50 kW |
| Shaft generator | 2 x STAMFORD A08D982953 375 kW/400V |
| Bow thrusters | Verhaar Omega200 kW. |
| Propeller | 2 x 4 blade variable pitch |
| Rudder | 2 conventional rudders |
