BERGEN STAR

Call signLNVH
IMO nr9321603
Year2006
DWT4157
LOA89,9m
Beam16,7m
Draft6,18m
GTR3618



IMO 9321603

CALL SIGN: LNVH

GENERAL
Where Built :RMK Shipyar Istanbul
Date Delivered:31. July 2006
Type of vessel:Oil Tanker
Type of hull:Double Hull
NATIONALITY, REGISTER, AND CLASS INFORMATION
Nationality/flagNOR
ClassBureau Veritas
Register notationBVI,+Hull,+Mach,Oil Tanker, Ice Class 1B,+ Aut-UMS, unristrited navigation, AVM-DPS
MAIN PARTICULARS
LOA (Length Over All):89,9 Metres
Extreme breadth:16,7 Metres
KTM (Keel to Masthead):32,0 Metres
Draught (fully loaded summer)6,18 Metres
Air draft in normal SBT condition?28.0 Metres
BCM (Bow to Center Manifold):40,4 Metres
Net Tonnage:1486
Gross Tonnage:3618
DWT4157
TANK ARRANGEMENT AND CAPACITY

Number of cargo tanks

10

Groups / Tank Capacities (m3 98%)



CT1P&SB  646,8

CT 2P&SB 1194,1

CT3P&SB  1303,3

CT4P&SB  1123

CT5P&SB  841,5

Total cubic capacity 98% ex slop tank:5108,7 Cu. Metres
Number of segregations10
Number of slop tanks1
Slop tank(s) capacity 98%:104 Cu. Metres
Cargo pumps

10 x 200 Cu. Metres/Hour At 10 Bar. Framo Hydraulic Deepwellpumps

Pumping capacity2.000 cbm/h
Vapour returnNo
IGSNo
Tank coatingEpoxy
Heating arrangementHeating coils in all cargo  and slop tanks
Heating capacity80° C.
Tank gauging systemRadar
Closed loading/samplingYes
Hose craneSWL 1t, Max. outreach 14.5 m
MOORING EQUIPTMENT
Number of ropes on drums forward4
Number of ropes on drums afterward4
Number of ropes on drums midship2
MACHINERY AND PROPULSION
Main engine2 x Bergen Diesel type C25:33 L6A, Rated Power 1740 kW at 900  RPM
Service speed14 knots
Aux. engines2 x Volvo Penta D12D-A MG Power 370Kw at 1800 Rpm
Shaft generator2 x 1280 kW
Bow thrustersBRUNVOLL FU-45-LTC-1375 500 kW.
Propeller2 x 4 blade, diameter 2300mm variable pitch
Rudder2 azipull propellers
